IEC certificated powerful 3v N20 dc brush toy vibration motor
Product Description:
Model |
N1015Z-060789670-0001 |
rated voltage |
3V DC |
starting voltage |
2.3V DC Max |
operating voltage |
2.5~3.6V DC |
rated current |
150mA Max |
rated speed |
11000±2500rpm |
stall current |
600mA Max |
vibration force |
2.5G Min @100g jig |
life |
2.5s on, 2.5s off, 50000 cycles |
terminal resistance |
6Ω±2Ω |
insulation resistance |
1MΩ Min |
mechanical noise |
45 db(A) Max |
Outline drawing:
Advantages:
1. the N20 toy vibration motor is with long-term technical support and customer service;
2. strict quality control and complete management system.
3. certificate of origin offered for some countries.
Application:
This N20 toy vibration motor electronic toy, smart product, home appliance, medical equipment, toothbrush
Our Main Products:
Company Profile:
Our company is engaged in the development, manufacturing and marketing of micro vibration motor since 2003 with 0.18 billion annual output, covering an area of 35,000sqm.
Linglong has its own independent R&D team for vibration motor and automation equipment, which enhance to develop new product and lower cost. Also the mature and advanced production lines guarantee large capacity and good quality. We have built a complete system for process, management and sales-service to better serve our clients.
Workshop:
Packaging & Shipping
1. Packaging: Carton
2. Shipping: By Air, Fedex, DHL, UPS, SF, etc for samples and batch goods, customer to pay for freight.
FAQ:
1. What is your main products?
We mainly specialize in small vibration motor, including dc coin motor, dc SMD motor, dc gear motor, dc stepper
motor and ac linear motor.
2. How can I get sample or place order?
To confirm the product specification at first, then we can send you datasheet and free samples for test. You can
send us order if sample without problem. You can contact us by anyway, email, skype, wechat, or phone.
3. Do you have MOQ?
We do not have MOQ limit, and accept small quanity order.
4. What is your terms for delivery and payment?
EXW, FOB, CFR, CPT for delivery; T/T, credit card or paypal for payment.
For more dc brush vibration motors, please contact us.
